RH-AUDIO 2 Way Coaxial Rimless In-ceiling Speaker

※ Rimless design with magnetically-attached grille
※ 2 way coaxial sound system with crossover.
※ Multiple rated power levels.
  • Description
  • Specification
The RH-AUDIO 2 Way Coaxial Rimless In-ceiling Speaker RH-THR20 or RH-THR30 is a new rimless design with magnetically-attached grille.

2 way coaxial sound system with a woofer helps to reduce distortion for improved clarity. 1" titanium dome tweeter improves sound dispersion by directing crisp, clear, and accurate higher frequency sounds to fit any room. A high-grade crossover utilizes oxygen free copper inductors, high watt ceramic resistors, and high quality capacitors.
The speaker includes a reveal magnetic rimless grille,which attaches easily and covers the lip. Once installed, no part of the speaker shows except for the grill, having the speaker virtually disappear into the installation environment. Making the speaker a true labor and time saver.

Ideally suited for installation in areas for the sound reproduction of reading announcements and playing background music such as shopping malls,restaurants, stations, hotels,home audio system etc.

Specifications of RH-AUDIO 2 Way Coaxial Rimless In-ceiling Speaker

Model

RH-THR20

RH-THR30

Rated Power

5W/10W/20W

7.5W/15W/30W

Input Voltage

100V

100V

Frequency Response

80Hz-20KHz

70Hz-20KHz

Sensitivity(1w,1n)

88±3 dB

89±3 dB

Hole for mounting

Φ180mm

Φ210mm

Dimension

Φ203*85mm

Φ232*90mm

Finished

White

White

Material

ABS enclosure & metal grille

Speaker Driver

5"*1+1"*1

6"*1+1"*1

Net Weight

1.47kg

1.80kg
